Deploy and Host Collabora Online (CODE) on Railway

Collabora Online Development Edition (CODE) is a powerful, enterprise-ready, open-source online office suite that enables collaborative editing of word processing documents, spreadsheets, and presentations directly within web applications like Nextcloud, ownCloud, and custom WOPI integrations. This Railway template deploys collabora/code:latest as a single container service listening on port 9980.

About Hosting Collabora Online

Hosting Collabora Online on Railway runs a single container instance using collabora/code:latest. The service acts as an editing engine using the WOPI protocol, rendering and editing documents provided by a host storage system (such as Nextcloud or ownCloud). Because Railway terminates TLS at its edge proxy, Collabora is configured with --o:ssl.enable=false in extra_params to accept HTTP traffic internally on port 9980 while serving secure HTTPS externally.

Common Use Cases

Real-time document co-authoring: Edit DOCX, XLSX, PPTX, and ODF files simultaneously with multiple users inside your browser.
Nextcloud / ownCloud Office backend: Seamlessly integrate with self-hosted storage platforms to provide native web office functionality.
Embedded document viewer & editor: Add rich document editing capabilities into custom WebDAV or WOPI-compliant web applications.
Privacy-focused productivity suite: Retain total control over corporate documents and sensitive files on private cloud infrastructure.

Dependencies for Collabora Hosting

Collabora image: collabora/code:latest
Railway public domain mapped to port 9980
Auto-generated credentials: Admin console username (12 chars) and password (32 chars)
Proxy SSL setting: --o:ssl.enable=false (configured in extra_params)

Upstream: Collabora Office Site · GitHub · Docker Hub

Implementation Details

Item	Value
Image	`collabora/code:latest`
WOPI / Web Port	`9980`
Storage / Volume	None (Stateless)
SSL Mode	Proxy Terminated (`--o:ssl.enable=false`)
Domain	`${{RAILWAY_PUBLIC_DOMAIN}}`

Topology

Service	Role	Volume	Public	Notes
collabora	CODE Office Engine & WOPI Server	None	Yes (Port `9980`)	Stateless container serving WOPI clients

Volumes (drives) — what to mount

This container is stateless. Documents are loaded into memory for editing and saved directly back to the host application (e.g. Nextcloud) via WOPI API calls.

Quick Start

Click the Deploy on Railway button above.
Sign in (or create a free Railway account) and click Deploy.
Wait 1–2 minutes for the collabora container to provision.
Retrieve your auto-generated admin credentials (username and password) from the Variables tab.
Open the collabora service → Settings → Networking and copy the generated public domain URL (e.g. https://collabora-production.up.railway.app).
Connect Collabora to your host application:
- In Nextcloud, go to Administration settings → Nextcloud Office.
- Select Use your own server and enter your Railway public URL.

Configuration

Container-level choices defined in the template:

Variable	Default / Source	Description / Notes
`domain`	`${{RAILWAY_PUBLIC_DOMAIN}}`	Allowed host domain regex for WOPI connection handshakes
`username`	Auto-generated secret (12 chars)	Username for accessing the Collabora admin console (`/browser/dist/admin/admin.html`)
`password`	Auto-generated secret (32 chars)	Password for accessing the Collabora admin console
`extra_params`	`--o:ssl.enable=false`	Disables internal TLS because Railway's edge proxy manages SSL termination
`PORT`	`9980`	Internal HTTP port the server listens on

Custom Domain & WOPI Setup

Open the collabora service → Settings → Networking → Custom Domain.
Add your custom domain (e.g., office.yourdomain.com) and configure DNS records as instructed.
If connecting to a Nextcloud instance on a specific domain, update the domain variable to include your Nextcloud domain regex (e.g., nextcloud\\.yourdomain\\.com).

Updating Collabora

Open the collabora service → Settings → Source.
Update the image tag (e.g., collabora/code:latest to a specific release tag).
Click Redeploy.

Traps

Common pitfalls and failure modes:

Internal SSL Conflict (--o:ssl.enable=false) — Railway handles edge HTTPS encryption and routes HTTP traffic to port 9980. Removing --o:ssl.enable=false causes Collabora to expect raw SSL sockets, producing 502 Bad Gateway errors.
WOPI Host Domain Rejection — Collabora restricts document requests to authorized domains. If domain is set too strictly or doesn't match your Nextcloud server's domain name, document loading will fail with "Access denied" errors.
Discovery Endpoint Connection Failure — Host applications verify Collabora availability by fetching https://${{RAILWAY_PUBLIC_DOMAIN}}/hosting/discovery. Ensure public domain networking is enabled and reachable.
Resource Constraints during Document Rendering — Complex spreadsheets or large PDF/DOCX presentations require memory during conversion. Ensure sufficient RAM is allocated to avoid container OOM kills.
