Deploy and Host MAS and Synapse on Railway
Matrix Authentication Service (MAS) is an identity provider that enables secure login and account management for Matrix clients. Synapse is the reference homeserver implementation for the Matrix protocol, powering decentralized communication. Together, they provide authentication and messaging infrastructure for Matrix-based applications.
About Hosting MAS and Synapse
Hosting MAS and Synapse on Railway involves deploying two tightly integrated services: Synapse as the homeserver and MAS as the authentication provider. Each service requires its own PostgreSQL database and a set of environment variables for secrets, endpoints, and client configuration. Railway simplifies this process by auto-injecting service domains and database credentials, reducing manual setup. With MAS handling OIDC flows and Synapse managing communication, you can run a full Matrix stack with minimal effort. This setup is ideal for developers, communities, or organizations wanting to host secure, scalable, and decentralized communication infrastructure without managing servers directly.
Why Deploy MAS and Synapse on Railway
Railway is a singular platform to deploy your infrastructure stack. Railway will host your infrastructure so you don't have to deal with configuration, while allowing you to vertically and horizontally scale it.
By deploying MAS and Synapse on Railway, you are one step closer to supporting a complete full-stack application with minimal burden. Host your servers, databases, AI agents, and more on Railway.
Common Use Cases
Running a personal or community Matrix homeserver with secure authentication
Integrating Element Web with MAS for OIDC-based login flows
Hosting scalable, production-ready Matrix infrastructure with minimal configuration
Dependencies for MAS and Synapse Hosting
PostgreSQL databases: One dedicated database for Synapse, one for MAS
RSA signing key: Required by MAS to sign tokens and enable secure authentication
Deployment Dependencies
Railway-managed PostgreSQL instances
Railway environment variable injection (RAILWAY_PUBLIC_DOMAIN, RAILWAY_PRIVATE_DOMAIN)
Matrix Synapse Documentation
Matrix Authentication Service (MAS) GitHub (github.com in Bing)
Template Content
synapse
Penghuot/ess-helmPORT
Port Synapse listens on inside the container. Example: 8008
MAS_CLIENT_ID
OIDC client ID registered for Synapse with MAS. Example: 0000000000000000000SYNAPSE
MAS_PUBLIC_URL
Public URL of MAS service. Example: https://mas-service-production-6c0a.up.railway.app
MAS_CLIENT_SECRET
OIDC client secret registered for Synapse with MAS. Example: 7XG6t2DaxVLtk81T3JaPRO9c3GBsfhapSutjnn/ieGE=
MAS_MATRIX_ENDPOINT
Public endpoint of MAS service. Example: https://mas-service-production-6c0a.up.railway.app
SYNAPSE_FORM_SECRET
Secret used for CSRF protection in Synapse forms. Example: 574308507c1054af6354fcfe02d580120f01349e5b5abd6e0194e69beb531983
MAS_MATRIX_SHARED_SECRET
Shared secret for secure communication with MAS. Must match MAS side. Example: 95946d21b1ae4cf8aef0c801b44dd35226d7a5f1ca500c08563151e128a89398
SYNAPSE_MACAROON_SECRET_KEY
Secret key used to sign macaroons (auth tokens). Example: 8f8f25f9a17fa9a7b495f8e8f44b9344ca47081f5defb0416b57b241c5d56284
mas-service
Penghuot/ess-helmMAS_CLIENT_ID
OIDC client ID registered for Synapse. Example: 0000000000000000000SYNAPSE
ELEMENT_WEB_URL
Public URL of your Element Web client. Example: https://web-element-production-1fad.up.railway.app
MAS_SIGNING_KEY
RSA private key used by MAS to sign tokens. Example: -----BEGIN RSA PRIVATE KEY----- ... -----END RSA PRIVATE KEY-----
MAS_EMAIL_DOMAIN
Domain used for email addresses issued by MAS. Example: matrix.synape-production-7433.up.railway.app
MAS_CLIENT_SECRET
OIDC client secret registered for Synapse. Example: 7XG6t2DaxVLtk81T3JaPRO9c3GBsfhapSutjnn/ieGE=
MAS_ENCRYPTION_KEY
Key used by MAS for encrypting sensitive data. Example: e30ced82286c06d0d873277811e4d004afb200744080969cad9cebbbda4d0149
MAS_MATRIX_ENDPOINT
Public endpoint MAS uses to reach Synapse. Example: https://synape-production-7433.up.railway.app
ELEMENT_WEB_CLIENT_ID
OIDC client ID registered for Element Web. Example: 00000000000000000000SEC0ND
MAS_MATRIX_HOMESERVER
The domain name of the homeserver. Example: synape-production-7433.up.railway.app
MAS_MATRIX_SERVER_NAME
The internal server name for your Matrix homeserver. Example: synape-production-7433.up.railway.app
MAS_CLIENT_REDIRECT_URI
Redirect URI Synapse uses for OIDC callback. Example: https://synape-production-7433.up.railway.app/_synapse/client/oidc/callback
MAS_MATRIX_SHARED_SECRET
Shared secret for secure communication between MAS and Synapse. Example: 95946d21b1ae4cf8aef0c801b44dd35226d7a5f1ca500c08563151e128a89398
MAS_MATRIX_PUBLIC_ENDPOINT
The public HTTPS endpoint MAS uses to reach Synapse. Example: https://synape-production-7433.up.railway.app
